AS9 Extra slim surface install led profile light 8x9mm

  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
  • AS9 Extra slim surface install led profile light 8x9mm Manufacturers, AS9 Extra slim surface install led profile light 8x9mm Factory, Supply AS9 Extra slim surface install led profile light 8x9mm
AS9 Extra slim surface install led profile light 8x9mm
  • LW-AS9
  • W8mm *H9mm
  • 6063-T5 Silver anodized Aluminium
  • Silver/Black/White/Custom
  • PC: Opal, Frost, Clear
  • Most LEDWIDE strips up to 11.2mm wide & 14.4W/m
  • 2m, 2.5m in stock, max 6m upon request

As slim as pencil, best to fit max. 5mm wide strip 2110.

AS9 Surface Mount Led Aluminum Profile Specification:
Item No.LW-AS9
DimensionW8mm*H9mm
Beam angle110 degrees
Max strip width5.7mm
Power consumption<19.2W/m
Length2m, 2.5m in stock, max 6m upon request
Weight0.16kg/m
Aluminum profileTemper: T5
Grade: 6063 series
Diffuser materialPMMA/PC
Diffuser colorOpal/Milky/Frosted/Clear
AccessoriesPlastic endcap with hole/ without hole
Plastic clip/Metal clip/Adjustable clip
Led strip5050/3528/2835/5730 are available
Surface treatmentSilver anodized
Customized ColorColor Anodized/Powder Coated/Spray Painting
InstallationSurface
Apply ToIndoor application
MOQ100m/item
Warranty5 years
CertificationCE, RoHs, SGS


AS9 Surface Mount Led Aluminum Profile Features:

# Low-profile surface but wider, available with wider flexible strips

# Designed to build small and delicate light fixtures

# You can achieve the effect of a mild accent illumination



Applications:

# Bookshelf lighting and cupboard lighting

# As interior lighting, light cabinets, glass cases etc

# Designed to be mounted to the surface with clips


Accessories:

Extra slim surface install led profile light


Multi-View:

  Extra slim surface install led profile light

Product Advantages:

Extra slim surface install led profile lightExtra slim surface install led profile light


Extra slim surface install led profile light
